10,000L Chassis Mount Diesel Transport Tank

10,000 litre tank suitable for diesel transport - suitable for direct-to-chassis mounting only.

This tank is supplied with spring-loaded mounting brackets which must be used otherwise warranty is void.
Standard fittings include:
Pressure & Vacuum vent with rollover shutoff valve.
80mm combination fill & dip tube with lockable cap
Calibrated dipstick of 20x20x3mm black anodised aluminium with replaceable wear plug.
Rollover coaming with dual drain points.

"Combustible Fluid" and diesel signs
50mm bottom outlet with ball valve, Kamlok & chained cap (see options)

4 x spring-loaded mounting brackets
Painted white 2 part epoxy enamel - white

The vehicle mounted half of the spring-loaded bracket is supplied separately to be bolted to the vehicle chassis rails.

This tank is suitable for diesel only - if you require a tank that is compliant to AS2809 for use on a DG Approved vehicle for transport of Class 3 Flammable liquids (ie ULP, Aviation fuels, Kerosene) please contact us on 1800-025 869 or sales@fuelequipment.com
